UltraFocus X-Ray Imaging System

Faxitron

UltraFocus X-Ray Imaging System


Enquire



The compact and fully-shielded x-ray cabinet can be placed directly on the bench top in your lab or wherever you need easy access to imaging.

Multiple detector sizes coupled with the wide energy range from 10-100kV makes the UltraFocus ideal for imaging a broad range of samples.  The 8µm focal spot and up to 10X geometric magnification provide up to 100 lp/mm resolution images.

The advanced Automatic Exposure Control allows the system to automatically select the appropriate exposure time and kV settings for the sample, with a single click of the mouse.

Features

  • No additional X-ray shielding required
  • No specialized X-ray knowledge needed to operate
  • Plugs into any standard A/C outlet
  • Stainless steel inner chamber designed for easy cleaning
  • Laser centering guide & transparent window ensure proper sample positioning
  • Magnification shelf with field of view guides and automatic position detection provides for up to 6X geometric magnification with accurate measurements at any level
  • 10X magnification tray provides up to 100 lp/mm resolution images for ex vivo and seed imaging
  • Single click calibration with auto object detect allows for simple, error-free calibration
  • One button operation with Automatic Exposure Control (AEC) optimized for a variety of samples (manual exposure settings also available)
  • Images instantaneously displayed on 22” high resolution 2.3 MP monitor
  • Remote diagnostic and support over the Web

Specifications

UltraFocus60

Energy range 10 - 60 kV
Sample imaging area 10cm x 15cm (4" x 6")
Pixel pitch 48µm
Spatial resolution Up to 100lp/mm at 10X geometric magnification
Tube current 0.3mA max (isowatt limited to 12 W from 41-100 kV)
Focal spot size, nominal 8µm
Window filtration 0.01" Be, tungsten source
Typical image acquisition time 10 seconds
Power 100-240 VAC+/- 10% 50/60 Hz, 150 VA
Dimensions, external 59cm W x 54cm D x 90cm H
Dimensions, internal 39cm W x 39cm D x 56cm H
Weight 188 kg

UltraFocus100

Energy range 10 - 100 kV
Sample imaging area

A) 23cm x 29cm (9" x 11.5")

B) 10cm x 15cm (4" x 6")

Pixel pitch

A) 74.8µm

B) 48µm

Spatial resolution

A) Up to 67 lp/mm at 10X geometric magnification

B) Up to 100 lp/mm at 10X geometric magnification

Tube current 0.3mA max (isowatt limited to 12 W from 41-100 kV)
Focal spot size, nominal 8 µm
Window filtration 0.01" Be, tungsten source
Typical image acquisition time 10 seconds
Power 100-240 VAC+/- 10% 50/60 Hz, 150 VA
Dimensions, external 59cm W x 54cm D x 90cm H
Dimensions, internal 39cm W x 39cm D x 56cm H
Weight 188 kg
