Description
System Overview
The CompAI compact radiography unit is a technology designed for preclinical research and archival imaging. It provides a comprehensive radiographic imaging solution for:
Small animals up to 5kg
Seeds, nuts or plants
Artifacts and cultural pieces.
This system is equipped with a fully shielded X-ray cabinet.
Non-invasive, Non-destructive
Features & Benefits
Easy data acquisition
Once ready the imaging subject is placed on stage and imaging can begin, using the easy-to-use acquisition software.
20 second scan time
The CompAI has a fast scan time for high-throughput imaging.
Large scan area
The CompAI system allows for a variety of animal models and tissue samples to be imaged, from 10g ~ 5kg. (Scan Area: 11.4 x 14.6cm)
This allows users to image not only mice and rats, but other species such as non-human primates, fish, rabbits, etc.
Adjustable field of view and resolution
The CompAI system has several levels of magnification, adjust the field of view (FOV) and resolution to suite your specific needs.
1.0x, 1.5x, 2.0x, auto-sensed for ease of use.
Technical Specifications
-
Scan Method : 20-50kV Tungsten X-ray tube
-
Animal Size : Mice, rats, and animals of similar size (up to 5kg)
-
Image Area (maximum) : 11.4 x 14.6cm
-
Pixel Size : 49.5µm at 1x
-
Operating System : Windows 10
-
Dimensions (WxDxH) : 60 x 72 x 165 cm
-
Power : 110/240VAC, 50/60Hz, 200VA
-
Operating Temp : 10~40 °C
